(A)TOP WELDING LINE
TYPE: YR-603S-XX UP SERIES (U SHAPE)
PER BURNER LENGTH:760 MM |
| TYPE |
ACTIVE CURING LENGTH |
ＴOTAL LENGTH |
| 34 PCS |
25.84 METER |
15.90 METER |
| 28 PCS |
21.28 METER |
13.50 METER |
| 22 PCS |
16.72 METER |
11.10 METER |
| 16 PCS |
12.16 METER |
8.70 METER |
| 10 PCS |
7.60 METER |
6.30 METER |
| *Pollution gas unrecycleable |
|
TYPE: YR-603S-XX SP SERIES LENEAR CURING
PER CURING LENGTH:760 MM |
| 型 號 |
ACTIVE CURING LENGTH |
TOTAL LENGTH |
| 18 PCS |
13.68 METER |
14.40 METER |
| 15 PCS |
11.40 METER |
12.00 METER |
| 12 PCS |
9.12 METER |
9.60 METER |
| 9 PCS |
6.84 METER |
7.20 METER |
| *Pollution gas unrecycleable |
|
TYPE: YR-603NS-XX UP SERIES U SHAPE
PER BURNER LENGTH:1500 MM |
| 型 號 |
ACTIVE CURING LENGTH |
TOTAL LENGTH |
| 16 PCS |
24.00 METER |
14.30 METER |
| 12 PCS |
18.00 METER |
11.10 METER |
| 10 PCS |
15.00 METER |
11.10 METER |
| 8 PCS |
12.00 METER |
7.90 METER |
| *Pollution gas recycleable |
|
TYPE: YR-603NS-XX SP SERIES (LINEAR CURING )
PER BURNER LENGTH:1500 MM |
| TYPE |
ACTIVE CURING LENGTH |
TOTAL LENGTH |
| 8 PCS |
12.00 METER |
12.80 METER |
| 6 PCS |
9.00 METER |
9.60 METER |
| 4 PCS |
6.00 METER |
6.40 METER |
| *Pollution gas recycleable |
|
(B)BUTTOM WELDING LINE
TYPE: YR-603D-XX SP DOUBLE WAY LINEAR CURING |
| TYPE |
ACTIVE CURING LENGTH |
TOTAL LENGTH |
| 18 PCS |
13.68 METER |
14.40 METER |
| 15 PCS |
11.40 METER |
12.00 METER |
| 12 PCS |
9.12 METER |
9.60 METER |
| 9 PCS |
6.84 METER |
7.20 METER |
| *Pollution gas unrecycleable |
|
| GAS FLOW AND CONSUMPTION RATE FOR EACH BURNER |
| Burner length |
GAS FLOW |
GAS CONSUNMPTION |
| 760 MML |
0.12 M/HR |
0.264 KG/HR |
| 1500 MML |
0.30 M/HR |
0.66 KG/HR |
|
| BODY DIAMETER RANGE |
DIA. 52-DIA.170 MM |
| BODY HEIGHT RANGE |
60-300 MM |
| SPEED |
12-60 M/MIN |
|
| *All specifications, dimensions and design characteristics shown are subject to change without notice. |
